73
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
ENGINE SHEETMETAL ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 031485-00 Engine Shroud Access Door Assembly 1
2 031403 Radiator Screen 1
3 031487-00 Radiator Shroud Weldment 1
4 190260 Trim Seal, 5/8 Bulb x 1/8 Edge Thick 1
5 190259 Edge Trim, 7/16 Wide x 1/16 Edge Thick 1
6 190258 Trim Seal, 7/16 Bulb x 1/16 Edge Thick 4
7 006499 Horn Assembly 1
8 z Plain Washer, 5/16 Regular Type B 18
9 z Helical Spring Lock Washer, 5/16 Regular 24
10 z Hex Head Cap Screw, 5/16 - 18 UNC - 0.875 LG. Grade 5 14
11 z Hex Nut, 3/8 - 16 6
12 z Helical Spring Lock Washer, 3/8 Regular 6
13 z Plain Washer, 3/8 Regular Type B 12
14 z Cross Recessed Pan Head Screw, #10 - 24 - 5/8 4
15 z Hex Jam Nut, 5/16 - 18 4
16 z Hex Head Cap Screw, 3/8 - 16 UNC - 1.25 LG. Grade 5 6
17 031483-00 Right Hand Engine Shroud Support Weldment 1
18 031482-00 Left Hand Engine Shroud Support Weldment 1
19 005650 Cushioned Loop Clamp 1
20 007391 Clamp, 3 inch 1
21 031548 Air Intake Hose 1
22 022450 Clamp, 2-1/2 inch 1
23 031484-01 Air Cleaner Bracket 1
24 031551 Air Cleaner Band 1
25 031549 Air Cleaner Assembly with Filter Element 1
26 z Prevailing Torque Hex Nut, 5/16 All Metal Type 2
27 031552 Rain Cap Assembly 1
28 031267 Cushioned Loop Clamp, 0.625 Diameter 2
29 013111 Cushioned Loop Clamp, 1.25 Diameter 2
30 031486-00 Engine Upper Shroud Assembly 1
31 023758 Flexible Draw Latch 2
32 031404-01 Engine Top Hinge 1
z Standard Hardware Item - Available at your local hardware store.
