Finn B70 - Engine Peripheral Assembly

71
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
ENGINE PERIPHERAL ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 031482-00 Left Hand Engine Shroud Support Weldment 1
2 031483-00 Right Hand Engine Shroud Support Weldment 1
3 z Hex Nut, 1/4 - 20 2
4 z Helical Spring Lock Washer, 1/4 Regular 4
5 z Plain Washer, 1/4 Regular Type B 4
6 031521 Pump Assembly, Fuel Feed 1
7 031522-00 Fuel / Water Separator Assembly 1
--- Upper Body Housing Assembly 1
--- O-ring 1
031522-03 Filter Element 1
--- Float 1
--- Cup 1
--- Drain Plug 1
8 z Plain Washer, 5/16 Regular Type B 2
9 z Helical Spring Lock Washer, 5/16 Regular 2
10 z Hex Head Cap Screw, 5/16 - 18 UNC - 4.0 LG. Grade 5 8
11 031518-01 ECU Cover 1
12 031504 ECU (Supplied with Engine) 1
13 z Hex Head Cap Screw, 1/4 - 20 UNC - 1.25 LG. Grade 5 1
z Standard Hardware Item - Available at your local hardware store.
