Finn B70 - Control Box Mount Assembly (Standard Trailer Model)

47
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
CONTROL BOX MOUNT ASSEMBLY
(STANDARD TRAILER MODEL)
Ref. No. Part Number Description No. Req’d
1 z Hex Nut, 3/8 - 16 2
2 z Helical Spring Lock Washer, 3/8 Regular 2
3 z Plain Washer, 3/8 Regular Type B 4
4 z Prevailing Torque Hex Nut, 1/4 All Metal Type 4
5 z Plain Washer, 1/4 Regular Type B 8
6 031490-01 Control Box Mount Bracket 1
7 z Hex Head Cap Screw, 3/8 - 16 UNC - 1.0 LG. Grade 5 2
8 z Hex Head Cap Screw, 1/4 - 20 UNC - 1.0 LG. Grade 5 4
9 031515 Control Box Assembly 1
(See Control Box section for parts detail.)
z Standard Hardware Item - Available at your local hardware store.
1
2
3
4
5
6
7
8
9
3
5
