61
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
COUPLING GUARD, CLUTCH HANDLE
AND BATTERY ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 000427 Handle Grip, Black 1
2 031302 Clutch Lever (Skid and Right-hand Feed Models) 1
3 031144 Clutch Lever (Trailer Models Only) 1
4 031514 Coupling Guard 1
5 z Plain Washer, 1/4 Regular Type B 4
6 z Helical Spring Lock Washer, 1/4 Regular 4
7 z Hex Head Cap Screw, 1/4 - 20 UNC - 0.75 LG. Grade 5 4
8 z Hex Nut, 3/8 - 16 2
9 z Helical Spring Lock Washer, 3/8 Regular 2
10 z Plain Washer, 3/8 Regular Type B 8
11 031368 Battery Holddown Strap 1
12 002256-12 Battery 1
13 z Hex Head Cap Screw, 3/8 - 16 UNC - 1.75 LG. Grade 5 2
14 z Prevailing Torque Hex Nut, 3/8 All Metal Type 2
15 031274 Split Coupling Insert 1
z Standard Hardware Item - Available at your local hardware store.
