43
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
SHREDDER BOX AND FEED CHUTE
(R-H MODEL)
Ref. No. Part Number Description No. Req’d
1 031292 Shredder Box Weldment 1
2 031293 Feed Chute Weldment 1
3 031289-01 Feed Chute Cover 1
4 031294 Feed Chute Extension 1
5 031295-01 Door 1
6 031096-04 Hinge Pin 1
7 031295-04 Left Leg Weldment 1
8 031295-05 Right Leg Weldment 1
9 z Hex Head Cap Screw, 3/8 - 16 UNC - 1.25 LG. Grade 5 4
10 z Plain Washer, 3/8 Regular Type B 16
11 z Prevailing Torque Hex Nut, 3/8 All Metal Type 8
12 z Hex Head Cap Screw, 3/8 - 16 UNC - 1 LG. Grade 5 4
13 z Plain Washer, 5/16 Regular Type B 8
14 z Hex Head Cap Screw, 5/16 - 18 UNC - 0.75 LG. Grade 5 3
15 z Prevailing Torque Hex Nut, 5/16 All Metal Type 4
z Standard Hardware Item - Available at your local hardware store.
