22
DMP10 / DMP20
Technical Data
Visual indications
Graphical display with automatic flip view (can be disabled) allows optimum
reading in different measuring positions
Colored illumination strip to signal measurement acquisition, limit violation
and battery charging status
Connections
2 USB female jacks, type C
USB 3.1, 900 mA/5 V=, at gauge bottom: for connecting digital Fischer probe
for fast charging the Li-Ion rechargeable battery in the gauge
USB 3.1, 500 mA/5 V=, at gauge top: for charging the Li-Ion rechargeable
battery in the gauge
for connection to a PC for data transfer max. cable
length: 3 m (118 ")
Weight
Gauge with rechargeable battery: 276 g (0.61 lb)
Dimensions
Scope of supply
Gauge, Li-Ion rechargeable battery, USB cable type C to type A (1,5 m/59.06 "),
safety information and quick guide, lanyard, gauge case
28 mm
1.10 "
70 mm / 2.76 "
38 mm
1,50 "
50 mm
1.97 "
129 mm / 5.08 "
