66
Evaluation DMP10 / DMP20
10 Evaluation
The gauge provides you with the mathematical calculations, complex and extensive
at times, needed for statistical evaluation of the measured readings from the batch.
The evaluation refreshes continuously in the background during the measurement.
The statistical characteristic variables of the batch are displayed in the Statistics
menu.
10.1 Batch statistics
Display statistical characteristic variables for all
measured readings of the batch: > Statistics >
OK.
Display histogram for all measured readings of the
batch (possible from 5 measured readings): >
Statistics > OK > > Batch Charts > OK > Histo-
gram > OK.
If no measurement data appear for the class divi-
sion, the display refers to the entire measurement
range of the connected probe.
Description of the characteristic variables, see
page 14
Example of batch statistics
NF/FE
Batch Statistics
n 9 x 274.4
s 2.67 R 8.5
V[%] 1.0 Min 271
Max 280 <LSL 0
>USL 0
[ ]
[ ]
