28
Rechargeable battery DMP10 / DMP20
Alternative 1 – quick charging using a commercially available travel charger:
► Insert the USB-C plug of the charging cable into the USB-C socket on the
underside of the gauge (probe connection).
Battery charging time is approx. 3 h, a green light strip on the switched-off
gauge signals the end of the charging process
Alternative 2 – charge the battery using an external charger for model
RRC1130 (available from Fischer as an accessory).
a Switch off the gauge, .
b Remove the battery from the gauge, 25.
c Refer to the safety Information on page 25.
d Place the battery in the external charger.
Instructions for handling the external charger can be found in the Operator's
Manual concerned.
1. 2.
USB-C plug of charging cable
[ ]
