Fisher & Paykel OB60C Series User Manual

16
3.7 Temperature Sensor
Voltage: 5 VDC
Max current: 2 mA
Max ambient temp: 540°C
Resistance: 1080 ohms +/– 5 ohms at 21°C
Refer to the chart on the following page for
sensor values.
Degrees ºC Degrees ºF Resistance Ω
0 32 1000
1 33.8 1004
2 35.6 1008
3 37.4 1011
4 39.2 1015
5 41 1019
6 42.8 1023
7 44.6 1027
8 46.4 1030
9 48.2 1034
10 50 1038
11 51.8 1042
12 53.6 1046
13 55.4 1049
14 57.2 1053
15 59 1057
16 60.8 1061
17 62.6 1065
18 64.4 1068
19 66.2 1072
20 68 1076
21 69.8 1080
22 71.6 1084
23 73.4 1087
24 75.2 1091
25 77 1095
26 78.8 1099
27 80.6 1102
28 82.4 1106
29 84.2 1110
30 86 1114
OB60 Models
