42
6 DIAGNOSTICS
To enter the mode:
1. Ensure all oven modes and temperature displays are set to OFF.
2. Ensure no cooking auto functions are set.
3. Enter the Technician Mode by pressing and holding the “Cancel Button” (X) on the clock for approx 2
seconds, then remove nger.
4. Then press the “OK Button” (√ ) once on the clock.
5. Push & hold the < > buttons together for 2 seconds.
The display will then show the word “wait” as it does a self check between the user interface (UI) and
power board (PB).
6. To scroll through the ve sub menu’s use the < > buttons.
7. To enter a sub menu press the “OK” (√ ) button.
8. To exit a sub menu press the (X) button.
NOTE: The OB60C oven use a global oven electronic platform controller (GEOP) which is a universal
controller used in other OB models. Ensure correct model ID is selected for the model you are working
on.
6.1 Entering the Technician Mode
“wait” is shown
like the photo
example
6.2 Technician Mode Navigation
Once in Technician Mode there are 5 possible menus:
This is the functional menu, which allows individual components to be test run.
• To scroll to each component use the <> Buttons
• To turn the component on and o use the “OK Button”(√ )
Function chart on following page.
Menu 1 - Elements
To Next Page
