43
Symbol Component Wattage (W)
UI Upper Inner Element
2000
Uo Upper Outer Element
1200
LI Lower Inner Element 1500
Lo Lower Outer Element Not used in OB2
FE Fan Element 2500
CF Cavity Fan 30
LF Low Speed Cooling Fan 20 (non pyro)
60 + resistor
(pyro)
HF High Speed Cooling Fan 60
ro Rotisserie motor 5
Lt Lights 100
UV Upper Vent actuator 6
LV lower vent actuator 6
LC Lock Motor
1. Door Switch must be in the closed position
2. Short delay and LCD will display “ON”
3. Will show “of” when turned o
Menu 2 - Model ID
This menu will show the model ID of the product, to enter press the “OK Button”(√ )
A number will be displayed, and will scroll in the display, ensure the correct region is set as there are
di erent cooking pro les for di erent models.
Note: If changing a power board or clock module, always check that the correct model ID is set.
