Fisher & Paykel OB60C Series - Removing the Bake Element; Removing the Cavity Fan

54
8.5 Removal of the Bake Element
•
Remove the product from the joinery
• Remove the rear panel to gain access to the
bake element.
• Remove wiring to the element.
• Lift the insulation to gain access to the
securing screws.
• Remove the screws and slide the element
out from under the oven cavity.
8.6 Removal of the Cavity Fan
•
Remove the product from the joinery
• Remove the fan shroud as per instruction 8.2.
• Remove the fan blade by removing the nut, hold
the fan blade while undoing the nut, which is left
hand thread.
• Remove the rear panel to gain access to the fan
motor.
• Remove the wiring to the fan motor, and then
remove the 3 screws and pull the fan motor out
from the cavity.
• Reassemble in reverse order.
