Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—AO Function Block
July 2013
123
Table 4‐25. Analog Output Function Block Parameter Definitions (Continued)
Description
Initial
Value
Range
Block
Mode
RO /
RW
Index
Number
Label
PARAMETER_NAME
Fault State Value
FSTATE_VAL
24 ALL PV Scale +/- 10% 0
Data Type: Float
Preset value to use if I/O_OPTS Fault State to Value
or Use Fault State Value on Restart is set.
Back Calculation Output
BKCAL_OUT
25 RO N/A
Status Limits
Dynamic
Data Type: DS‐65 The value and
status required by the BKCAL_IN input of another
block to prevent reset windup and to provide
bumpless transfer to closed loop control.
Value
Remote Cascade Input
RCAS_IN
26 ALL
Status
BAD: NoCom:
NoVal:
const
Data Type: DS‐65
Target SP and status by supervisory host
Value 0 Trk
Shed Options
SHED_OPT
27 ALL
Defined by FF spec
0=Invalid
1=Normal Shed,
Normal Return
2=Normal Shed, No
Return
3=Shed to Auto,
normal return
4=Shed to Auto, no
return. Target mode
changes to Auto on
detection of a shed
condition
5=Shed to Manual,
normal return
6=Shed to Manual, No
return. Target mode
changes to MAN on
detection of a shed
condition.
7=Shed to retained
target, normal return
8=Shed to retained
target, no return.
(Change target to
retained target)
0
Data Type: Unsigned8
Defines the action to be taken when the set point is
not updated in a remote mode.
Remote Cascade Output
RCAS_OUT
28 RO N/A
Status
Dynamic
Data Type: DS‐65
Block set point and status after ramping
Value
Update Event
UPDATE_EVT
29
Data Type: DS‐73
This alert is generated by any changes to static data.
UNACKNOWLEDGED 29.1 RW N/A
0:Undefined
1:Acknowledged
2:
Unacknowledged
0: Undefined
UPDATE_STATUS 29.2 RO N/A
0:Undefined
1:Update reported
2:Update not reported
0: Undefined
TIME_STAMP 29.3 RO N/A 0
STATIC_REVISION 29.4 RO N/A 0
RELATIVE_INDEX 29.5 RO N/A 0
Block Alarm
BLOCK_ALM
30
Data Type: DS‐72
The block alarm is used for all configuration,
hardware, connection failure, or system problems
in the block.
UNACKNOWLEDGED 30.1 RW N/A
0:Undefined
1:Acknowledged
2:
Unacknowledged
0: Undefined
ALARM_STATE 30.2 RO N/A
0:Undefined
1:Clear reported
2:Clear not reported
3:Active reported
4:Active not reported
0: Undefined
TIME_STAMP 30.3 RO N/A 0
SUBCODE 30.4 RO N/A 0
VALUE 30.5 RO N/A 0
-Continued-
