Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—AO Function Block
July 2013
124
Table 4‐25. Analog Output Function Block Parameter Definitions (Continued)
Description
Initial
Value
Range
Block
Mode
RO /
RW
Index
Number
Label
PARAMETER_NAME
Extended Parameters
StdDev
STDDEV
31 RO N/A positive float Dynamic
Data Type: Float
Standard Deviation. To support DeltaV Variability
measurement.
Cap StdDev
CAP_STDDEV
32 RO N/A positive float Dynamic
Data Type: Float
Capability Standard Deviation. To support DeltaV
Variability measurement.
View Lists
View lists allow the values of a set of parameters to be accessed at the same time. Views 1 and 2 contain operating
parameters and are defined by the Fieldbus Foundation. View 3 contains dynamic parameters and View 4 contains
static parameters with configuration and maintenance information. Views 3 and 4 are defined by the manufacturer.
Table 4‐26. AO Function Block, View 1
Index Number Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 PV
8 SP
9 OUT
16 READBACK
17 CAS_IN
Table 4‐27. AO Function Block, View 2
Index Number Parameter
1 ST_REV
11 PV_SCALE
12 XD_SCALE
13.1 GRANT_DENY.GRANT
13.2 GRANT_DENY.DENY
20 SP_HI_LIM
21 SP_LO_LIM
Table 4‐28. AO Function Block, View 3
Index Number Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 PV
8 SP
9 OUT
16 READBACK
17 CAS_IN
25 BKCAL_OUT
26 RCAS_IN
28 RCAS_OUT
31 STDDEV
32 CAP_STDDEV
Table 4‐29. AO Function Block, View 4
Index Number Parameter
1 ST_REV
3 STRATEGY
4 ALERT_KEY
14 IO_OPTS
15 STATUS_OPTS
18 SP_RATE_DN
19 SP_RATE_UP
22 CHANNEL
23 FSTATE_TIME
24 FSTATE_VAL
27 SHED_OPT
