Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—PID Function Block
July 2013
142
Table 4‐35. PID Function Block, View 3
Index Number Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 PV
8 SP
9 OUT
15 IN
18 CAS_IN
27 BKCAL_IN
31 BKCAL_OUT
32 RCAS_IN
33 ROUT_IN
35 RCAS_OUT
36 ROUT_OUT
38 TRK_IN_D
39 TRK_VAL
40 FF_VAL
45.1 ALARM_SUM.CURRENT
45.2 ALARM_SUM.UNACKNOWLEDGED
45.3 ALARM_SUM.UNREPORTED
45.4 ALARM_SUM.DISABLED
67 ERROR
68 SP_WORK
71 STRUCTURECONFIG
75 STDDEV
76 CAP_STDDEV
Note
Because individual views are limited in size, View List 4 has
two parts.
Table 4‐36. PID Function Block, View 4.1
Index Number Parameter
1 ST_REV
3 STRATEGY
4 ALERT_KEY
13 CONTROL_OPTS
14 STATUS_OPTS
16 PV_FTIME
19 SP_RATE_DN
20 SP_RATE_UP
23 GAIN
24 RESET
25 BAL_TIME
26 RATE
30 BKCAL_HYS
34 SHED_OPT
37 TRK_SCALE
41 FF_SCALE
42 FF_GAIN
46 ACK_OPTION
47 ALARM_HYS
48 HI_HI_PRI
49 HI_HI_LIM
50 HI_PRI
51 HI_LIM
52 LO_PRI
53 LO_LIM
54 LO_LO_PRI
55 LO_LO_LIM
56 DV_HI_PRI
57 DV_HI_LIM
58 DV_LO_PRI
59 DV_LO_LIM
Table 4‐37. PID Function Block, View 4.2
Index Number Parameter
1 ST_REV
66 BIAS
69 SP_FTIME
70 MATHFORM
71 STRUCTURECONFIG
72 GAMMA (ugamma)
73 BETA
74 IDEADBAND
