Detailed Setup—ISEL Function Block
July 2013
158
Table 4‐41. ISEL Function Block, View 1
Index Number Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 OUT
11 IN_1
12 IN_2
13 IN_3
14 IN_4
15 DISABLE_1
16 DISABLE_2
17 DISABLE_3
18 DISABLE_4
21 SELECTED
22 OP_SELECT
25 IN_5
26 IN_6
27 IN_7
28 IN_8
29 DISABLE_5
30 DISABLE_6
31 DISABLE_7
32 DISABLE_8
34.1 ALARM_SUM.CURRENT
34.2 ALARM_SUM.UNACKNOWLEDGED
34.3 ALARM_SUM.UNREPORTED
34.4 ALARM_SUM.DISABLED
Table 4‐42. ISEL Function Block, View 2
Index Number Parameter
1 ST_REV
8 OUT_RANGE
9.1 GRANT_DENY.GRANT
9.2 GRANT_DENY.DENY
Table 4‐43. ISEL Function Block, View 3
Index Number Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 OUT
11 IN_1
12 IN_2
13 IN_3
14 IN_4
15 DISABLE_1
16 DISABLE_2
17 DISABLE_3
18 DISABLE_4
21 SELECTED
22 OP_SELECT
25 IN_5
26 IN_6
27 IN_7
28 IN_8
29 DISABLE_5
30 DISABLE_6
31 DISABLE_7
32 DISABLE_8
34.1 ALARM_SUM.CURRENT
34.2 ALARM_SUM.UNACKNOWLEDGED
34.3 ALARM_SUM.UNREPORTED
34.4 ALARM_SUM.DISABLED
49 OUT_D
Table 4‐44. ISEL Function Block, View 4
Index Number Parameter
1 ST_REV
3 STRATEGY
4 ALERT_KEY
10 STATUS_OPTS
19 SELECT_TYPE
20 MIN_GOOD
33 AVG_USE
35 ACK_OPTION
36 ALARM_HYS
37 HI_HI_PRI
38 HI_HI_LIM
39 HI_PRI
40 HI_LIM
41 LO_PRI
42 LO_LIM
43 LO_LO_PRI
44 LO_LO_LIM
50 ALM_SEL
