Instruction Manual
D103412X012
Detailed Setup—OS Function Block
July 2013
169
Table 4‐48. Output Splitter Function Block Parameter Definitions (Continued)
Description
Initial
Value
Range
Block
Mode
RO /
RW
Index
Number
Label
PARAMETER_NAME
Block Alarm
BLOCK_ALM
24
Data Type: DS‐72
The block alarm is used for all configuration, hardware,
connection failure, or system problems in the block. The
cause of the alert is entered in the subcode field.
UNACKNOWLEDGED
24.1 RW N/A
0: Undefined
1: Acknowledged
2: Unacknowledged
ALARM_STATE
24.2 RO N/A
0: Undefined
1: Clear reported
2: Clear not reported
3: Active reported
4: Active not
reported
TIME_STAMP
24.3 RO N/A
SUBCODE
24.4 RO N/A
VALUE
24.5 RO N/A
View Lists
View lists allow the values of a set of parameters to be accessed at the same time. Views 1 and 2 contain operating
parameters and are defined by the Fieldbus Foundation. View 3 contains dynamic parameters and View 4 contains
static parameters with configuration and maintenance information. Views 3 and 4 are defined by the manufacturer.
Table 4‐49. OS Function Block, View 1
Index Number Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 SP
8 OUT_1
9 OUT_2
14 CAS_IN
Table 4‐50. OS Function Block, View 2
Index Number Parameter
1 ST_REV
10 OUT_1_RANGE
11 OUT_2_RANGE
12.1 GRANT_DENY.GRANT
12.2 GRANT_DENY.DENY
Table 4‐51. OS Function Block, View 3
Index Number Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 SP
8 OUT_1
9 OUT_2
14 CAS_IN
15 BKCAL_OUT
19 BKCAL_1_IN
20 BKCAL_2_IN
Table 4‐52. OS Function Block, View 4
Index Number Parameter
1 ST_REV
3 STRATEGY
4 ALERT_KEY
13 STATUS_OPTS
16 IN_ARRAY
17 OUT_ARRAY
18 LOCKVAL
21 BAL_TIME
