Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—AI Function Block
July 2013
179
Table 4‐57. Analog Input Block Parameter Definitions (Continued)
Description
Initial
Value
Range
Write Block
Mode
RO /
RW
Index
Number
Label
PARAMETER_NAME
Alarm Summary
ALARM_SUM
22
Data Type: DS‐74 Current alert status,
unacknowledged states, unreported states, and
disabled states of the alarms associated with the
function block.
0=clear
0=acknowledged
0=reported
0=enabled
CURRENT 22.1 RO ALL
0: Discrete alarm
1: Hi Hi alarm
2: Hi Alarm
3: Lo Lo Alarm
4: Lo Alarm
7: Block alarm
 UNACKNOWLEDGED 22.2 RO ALL
UNREPORTED 22.3 RO ALL
DISABLED 22.4 RW ALL All bits: 0
Acknowledge Option
ACK_OPTION
23 ALL
0: Discrete alarm
1: Hi Hi alarm
2: Hi Alarm
3: Lo Lo Alarm
4: Lo Alarm
7: Block alarm
All bits: 0
Data Type: Bit String
0
=Disable
1
=Enable
Selection of whether alarms associated with the
block will be automatically acknowledged.
Alarm Hysteresis
ALARM_HYS
24 ALL 0 - 50% 0.50%
Data Type: Float
Hysteresis on alarms.
High High Priority
HI_HI_PRI
25 ALL 0 to 15 0
Data Type: Unsigned8
The priority of the hi hi alarm.
High High Limit
HI_HI_LIM
26 ALL OUT_SCALE 0
Data Type: Float
Value of analog input which will generate an alarm.
High Priority
HI_PRI
27 ALL 0 to 15 0
Data Type: Unsigned8
The priority of the high alarm.
Hi Limit
HI_LIM
28 ALL OUT_SCALE 0
Data Type: Float
Value of analog input which will generate an alarm.
Low Priority
LO_PRI
29 ALL 0 to 15 0
Data Type: Unsigned8
The priority of the low alarm.
Low Limit
LO_LIM
30 ALL OUT_SCALE 0
Data Type: Float
Value of analog input which will generate an alarm.
Low Low Priority
LO_LO_PRI
31 ALL 0 to 15 0
Data Type: Unsigned8
The priority of the low low alarm.
Low Low Limit
LO_LO_LIM
32 ALL OUT_SCALE 0
Data Type: Float
Value of analog input which will generate an alarm.
High High Alarm
HI_HI_ALM
33
Data Type: DS‐71
The status of the hi hi alarm and its associated time
stamp.
UNACKNOWLEDGED 33.1 RW
N/A
0
ALARM_STATE 33.2 RO 0
TIME_STAMP 33.3 RO 0
SUBCODE 33.4 RO 0
VALUE 33.5 RO 0
High Alarm
HI_ALM
34
Data Type: DS‐71
The status of the hi alarm and its associated time
stamp.
UNACKNOWLEDGED 34.1 RW
N/A
0
ALARM_STATE 34.2 RO 0
TIME_STAMP 34.3 RO 0
SUBCODE 34.4 RO 0
VALUE 34.5 RO 0
Low Alarm
LO_ALM
35
Data Type: DS‐71
The status of the lo alarm and its associated time
stamp.
UNACKNOWLEDGED 35.1 RW
N/A
0
ALARM_STATE 35.2 RO 0
TIME_STAMP 35.3 RO 0
SUBCODE 35.4 RO 0
VALUE 35.5 RO 0
-Continued-
