Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—AI Function Block
July 2013
181
Table 4‐60. AI Function Block, View 3
Index Number Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 PV
8 OUT
19 FIELD_VAL
22.1 ALARM_SUM.CURRENT
22.2 ALARM_SUM.UNACKNOWLEDGED
22.3 ALARM_SUM.UNREPORTED
22.4 ALARM_SUM.DISABLED
37 OUT_D
38 ALM_SEL
39 STDDEV
40 CAP_STDDEV
Table 4‐61. AI Function Block, View 4
Index Number Parameter
1 ST_REV
3 STRATEGY
4 ALERT_KEY
13 IO_OPTS
14 STATUS_OPTS
15 CHANNEL
16 L_TYPE
17 LOW_CUT
18 PV_FTIME
23 ACK_OPTION
24 ALARM_HYS
25 HI_HI_PRI
26 HI_HI_LIM
27 HI_PRI
28 HI_LIM
29 LO_PRI
30 LO_LIM
31 LO_LO_PRI
32 LO_LO_LIM
