Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—MAI Function Block
July 2013
187
View Lists
View lists allow the values of a set of parameters to be accessed at the same time. Views 1 and 2 contain operating
parameters and are defined by the Fieldbus Foundation. View 3 contains dynamic parameters and View 4 contains
static parameters with configuration and maintenance information. Views 3 and 4 are defined by the manufacturer.
Table 4‐65. MAI Function Block, View 1
Index Number Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
8 OUT_1
9 OUT_2
10 OUT_3
11 OUT_4
12 OUT_5
13 OUT_6
14 OUT_7
15 OUT_8
Table 4‐66. MAI Function Block, View 2
Index Number Parameter
1 ST_REV
Table 4‐67. MAI Function Block, View 3
Index Number Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
8 OUT_1
9 OUT_2
10 OUT_3
11 OUT_4
12 OUT_5
13 OUT_6
14 OUT_7
15 OUT_8
Table 4‐68. MAI Function Block, View 4
Index Number Parameter
1 ST_REV
3 STRATEGY
4 ALERT_KEY
7 CHANNEL
