Detailed Setup—DI Function Block
July 2013
209
Table 4‐81. Discrete Input Function Block Parameter Definitions (Continued)
DescriptionInitial ValueRange
Block
Mode
RO /
RW
Index
Number
Label
PARAMETER_NAME
Block Alarm
BLOCK_ALM
19 Dynamic
Data Type: DS‐72
The block alarm is used for all configuration,
hardware, connection failure, or system
problems in the block. The cause of the alert is
entered in the subcode field. The first alert to
become active will set the active status in the
status parameter. As soon as the unreported
status is cleared by the alert reporting
procedure, and other block alert may be
reported without clearing the active status, if
the subcode has changed.
UNACKNOWLEDGED 19.1 RW N/A
0=Undefined
1=Acknowledged
2=Unacknowledged
ALARM_STATE 19.2 RO N/A
0=Undefined
1=Clear reported
2=Clear not reported
3=Active reported
4=Active not reported
TIME_STAMP 19.3 RO N/A
SUBCODE 19.4 RO N/A
VALUE 19.5 RO
Alarm Summary
ALARM_SUM
20
0: Discrete alarm
7: Block Alarm
Data Type: DS‐74
The current alert status, unacknowledged
states, unreported states, and disabled states
of the alarms associated with the function
block.
0=clear reported
0=acknowledged
0=reported
0=enabled
CURRENT 20.1 RO All bits: 0
UNACKNOWLEDGED 20.2 RO All bits: 0
UNREPORTED 20.3 RO All bits: 0
DISABLED 20.4 RW All bits: 0
Acknowledge Option
ACK_OPTION
21 ALL
0: Discrete
1: Block Alarm
All bits: 0
Data Type: Bit String
0=Disable
1=Enable
Used to set auto acknowledgement of alarms
Discrete Priority
DISC_PRI
22 ALL 0 to 15 0
Data Type: Unsigned8
Priority of the discrete alarm.
Discrete Limit
DISC_LIM
23 ALL PV_STATE 0
Data Type: Unsigned8
State of discrete input which will generate an
alarm.
Discrete Alarm
DISC_ALM
24
Data Type: DS‐72
The discrete alarm is used for indication of a
state change in selected discrete channel.
UNACKNOWLEDGED 24.1 RW N/A
0=Undefined
1=Acknowledged
2=Unacknowledged
ALARM_STATE 24.2 RO N/A
0=Undefined
1=Clear reported
2=Clear not reported
3=Active reported
4=Active not reported
TIME_STAMP 24.3 RO N/A
SUBCODE 24.4 RO N/A
VALUE 24.5 RO N/A
