Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Field Communicator Menu Structure
July 2013
263
Transducer Block (TB) Menu Structure (Continued)
Menu StructureParameter Label
Input Characterization
TB > Configure/Setup > Detailed Setup > Response Control > Input Characterization
TB > Device Variables > Input Characterization
Integrator Limited Hi TB > Device Diagnostics > Status > Self Test Status > Integrator Limited Hi
Integrator Limited Lo TB > Device Diagnostics > Status > Self Test Status > Integrator Limited Lo
Integrator Suspended TB > Device Diagnostics > Status > Self Test Status > Integrator Suspended
IOP Failure TB > Device Diagnostics > Status > Self Test Status > IOP Failure
Last Calibration Type TB > Configure/Setup > Detailed Setup > Instrument > Last Calibration Type
Leak Class TB > Configure/Setup > Detailed Setup > Valve and Actuator > Trim > Leak Class
Length Units TB > Configure/Setup > Detailed Setup > Instrument > Length Units
Lever Arm Length TB > Configure/Setup > Detailed Setup > Valve and Actuator > Actuator > Lever Arm Length
Lever Style TB > Configure/Setup > Detailed Setup > Valve and Actuator > Actuator > Lever Style
Lost Static Data TB > Device Diagnostics > Status > Block Error > Lost Static Data
Lower Bench Set TB > Configure/Setup > Detailed Setup > Valve and Actuator > Actuator > Lower Bench Set
MAI Channel 1 TB > Configure/Setup > Detailed Setup > MAI Channel Map > MAI Channel 1
MAI Channel 2 TB > Configure/Setup > Detailed Setup > MAI Channel Map > MAI Channel 2
MAI Channel 3 TB > Configure/Setup > Detailed Setup > MAI Channel Map > MAI Channel 3
MAI Channel 4 TB > Configure/Setup > Detailed Setup > MAI Channel Map > MAI Channel 4
MAI Channel 5 TB > Configure/Setup > Detailed Setup > MAI Channel Map > MAI Channel 5
MAI Channel 6 TB > Configure/Setup > Detailed Setup > MAI Channel Map > MAI Channel 6
MAI Channel 7 TB > Configure/Setup > Detailed Setup > MAI Channel Map > MAI Channel 7
MAI Channel 8 TB > Configure/Setup > Detailed Setup > MAI Channel Map > MAI Channel 8
Maint Active TB > Configure/Setup > Detailed Setup > Alert Handling > Simulate Active Alerts > Maint Active
Maintenance Enable TB > Configure/Setup > Detailed Setup > Alerts > PlantWeb Alert Enable > Maintenance Enable
Maintenance Suppress TB > Configure/Setup > Detailed Setup > Alerts > PlantWeb Alert Reporting > Maintenance Suppress
Maximum Recorded Supply
Pressure
TB > Device Diagnostics > Device Record > Maximum Recorded Supply Pressure
Maximum Recorded Supply
Pressure Time
TB > Device Diagnostics > Device Record > Maximum Recorded Supply Pressure Time
Maximum Recorded
Temperature
TB > Device Diagnostics > Device Record > Maximum Recorded Temperature
Maximum Recorded
Temperature Time
TB > Device Diagnostics > Device Record > Maximum Recorded Temperature Time
Maximum Supply Pressure TB > Configure/Setup > Detailed Setup > Instrument > Maximum Supply Pressure
Minimum Recorded Supply
Pressure
TB > Device Diagnostics > Device Record > Minimum Recorded Supply Pressure
Minimum Recorded Supply
Pressure Time
TB > Device Diagnostics > Device Record > Minimum Recorded Supply Pressure Time
Minimum Recorded
Temperature
TB > Device Diagnostics > Device Record > Minimum Recorded Temperature
Minimum Recorded
Temperature Time
TB > Device Diagnostics > Device Record > Minimum Recorded Temperature Time
MLFB Error TB > Device Diagnostics > Status > Self Test Status > MLFB Error
Nominal Supply Pressure TB > Configure/Setup > Detailed Setup > Valve and Actuator > Actuator > Nominal Supply Pressure
Out of Service TB > Device Diagnostics > Status > Block Error > Out of Service
Outlet Pressure TB > Configure/Setup > Detailed Setup > Valve and Actuator > Valve > Outlet Pressure
Outblock Selection TB > Configure/Setup > Detailed Setup > Response Control > Outblock Selection
Output Block Timeout TB > Configure/Setup > Detailed Setup > Alerts > Configuration Alerts > Output Block Timeout
Output Block Timeout Alert TB > Configure/Setup > Detailed Setup > Alerts > Configuration Alerts > Output Block Timeout > Output Block Timeout Alert
Output Block Timeout Alert
Enable
TB > Configure/Setup > Detailed Setup > Alerts > Configuration Alerts > Output Block Timeout > Output Block Timeout Alert Enable
Output Block Timeout Manual
Recovery
TB > Configure/Setup > Detailed Setup > Alerts > Configuration Alerts > Output Block Timeout > Output Block Timeout Manual
Recovery
Output Block Timeout Shutdown TB > Configure/Setup > Detailed Setup > Alerts > Configuration Alerts > Output Block Timeout > Output Block Timeout Shutdown
Packing Type TB > Configure/Setup > Detailed Setup > Valve and Actuator > Valve > Packing Type
PD Inside Status TB > Configure/Setup > Device Variables > PD Inside Status
PD Run TB > Configure/Setup > Detailed Setup > Alerts > Performance Alerts > PD Run
−Continued−

Fisher FIELDVUE DVC6200f Specifications

General

Brand	Fisher
Model	FIELDVUE DVC6200f
Category	Controller
Language	English
