Detailed Setup—Resource Block
July 2013
58
Table 4‐3. Resource Block Parameter Definitions (Continued)
Description
Initial
Value
RangeMode
RO /
RW
Index
Number
Label
PARAMETER_NAME
Write Lock
WRITE_LOCK
34 RW ALL
0=Undefined
1=Unlocked
2=Locked
1=Unlocked
Data Type: Unsigned8
If set to Locked, no writes from anywhere are
allowed except to clear WRITE_LOCK by entering
Unlocked. Block inputs will continue to be
updated if they are subscribers. The feature Soft
Write Lock must be selected to enable writing to
this parameter (see Device Features in this
section).
Update Event
UPDATE_EVT
35
UNACKNOWLEDGED 35.1 RW ALL
0=Undefined
1=Acknowledged
2=Unacknowledged
0=Undefined
Data Type: DS‐73
This alert is generated by any change to the
static data. To support tracking changes in static
parameter values, the blocks static revision
parameter will be incremented each time a
static parameter value is changed. Also, the
blocks static revision parameter may be
incremented if a static parameter is written but
the value is not changed. If the Actual Mode is
not Out of Service and Reports is selected in the
Feature Select parameter, then this parameter
will be sent to the host system providing the
host has set up alert communications. Changes
to static data while the block is Out of Service
will be reported when the block transitions to
another mode.
UPDATE_STATE 35.2 RO NA
0=Undefined
1=Update reported
2=Update not
reported
0=Undefined
TIME_STAMP 35.3 RO NA 0
STATIC_REVISION 35.4 RO NA 0
RELATIVE_INDEX 35.5 RO NA 0
Block Alarm
BLOCK_ALM
36
UNACKNOWLEDGED 36.1 RW ALL
0=Undefined
1=Acknowledged
2=Unacknowledged
0=Undefined
Data Type: DS‐72
This alarm is generated by a nonzero value in the
Block Error. parameter. This alarm has a fixed
priority of 2. For a BLOCK_ALM to be broadcast
to the host the following conditions must be
met:
The feature Reports must be selected
Alert communication with the host must be
setup
In the ALARM_SUM parameter, the disable bit
for Block Alarm must be clear.
ALARM_STATE 36.2 RO NA
0=Undefined
1=Clear reported
2=Clear not reported
3=Active reported
4=Active not reported
0=Undefined
TIME_STAMP 36.3 RO NA 0
SUBCODE 36.4 RO NA 0
VALUE 36.5 RO NA 0
Alarm Summary
ALARM_SUM
37
CURRENT 37.1 RO NA
0: Discrete alarm
7: Block Alarm
All bits: 0
Data Type: DS‐74
0=clear, acknowledged, reported, enabled
Current alert status, unacknowledged states,
unreported states, and disabled states of the
alarms associated with the function block. The
Resource block only has two alarms: Write Alarm
and Block Alarm.
UNACKNOWLEDGED 37.2 RO NA
0: Discrete alarm
7: Block Alarm
All bits: 0
UNREPORTED 37.3 RO NA
0: Discrete alarm
7: Block Alarm
All bits: 0
DISABLED 37.4 RW ALL
0: Discrete alarm
7: Block Alarm
All bits: 0
Acknowledge Option
ACK_OPTION
38 RW ALL
0: Discrete Alarm
(Write Lock off)
7: Block Alarm
0: 0
7: 0
Data Type: Bit String
0=Disable
1=Enable
Selection of whether alarms associated with the
block will be automatically acknowledged.
Write Priority
WRITE_PRI
39 RW ALL 0 to 15 0
Data Type: Unsigned8
Priority of the alarm generated by setting
WRITE_LOCK to Unlocked.
-Continued-
