Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—Resource Block
July 2013
59
Table 4‐3. Resource Block Parameter Definitions (Continued)
Description
Initial
Value
RangeMode
RO /
RW
Index
Number
Label
PARAMETER_NAME
Write Alarm
WRITE_ALM
40
Data Type: DS‐72
This alarm is generated when Unlocked in the
WRITE_LOCK parameter is set. This alarm has a
priority of WRITE_PRI. For a WRITE_ALM to be
broadcast to the host the following conditions
must be met:
The feature Reports must be selected
Alert communication with the host must be
setup
In the ALARM_SUM parameter, the disable bit
for Write Alarm must be clear.
WRITE_PRI must be greater than 1.
UNACKNOWLEDGED 40.1 RW ALL
0=Undefined
1=Acknowledged
2=Unacknowledged
0=Undefined
ALARM_STATE 40.2 RO NA
0=Undefined
1=Clear reported
2=Clear not reported
3=Active reported
4=Active not reported
0=Undefined
TIME_STAMP 40.3 RO NA 0
SUBCODE 40.4 RO NA 0
VALUE 40.5 RO NA 0
ITK Version
ITK_VER
41 RO N/A *
Data Type: Unsigned16
Major version of ITK test this device has been
tested to. *Initial value depends on the revision
of the DVC6200f.
Extended Parameters
Private Label Distributor
DISTRIBUTOR
42 RO NA 0x5100
Data Type: Unsigned32
Private label distributor
Device String Array
DEV_STRING
43 Unused extended parameter.
Function Block Options
FB_OPTIONS
44 RO
Bits
0: AO
1: DO
2: AI
3: DI
4: PID
5: ISEL
6: OS
7: MAI
All options
enabled
Data Type: Bit String
0=disabled
1=enabled
Indicates which function block licensing options
are enabled. One bit for each block type that is
supported. Unlicensed blocks cannot be
scheduled and the Actual block mode will
remain OOS.
Diagnostic Options
DIAG_OPTIONS
45 RO NA
1=FD Fieldbus
Diagnostics
2=AD Advanced
Diagnostics
3=PD Performance
Diagnostics
*
Data Type: Enum
Indicates which diagnostics licensing options are
enabled. *Initial value depends on the licensed
DVC6200f options.
Miscellaneous Options
MISC_OPTIONS
46 RO NA
0: Software Download
10: Travel Control
Capable
11: Pressure Control
Capable
12: Fallback Capable
FD
0: 1
10: 1
11: 1
AD/PD
0: 1
10: 1
11: 1
12: 1
Data Type: Bit String
0=Disable
1=Enable
Indicates which miscellaneous licensing options
are enabled.
Firmware Revision
FIRMWARE_REVISION
47
Data Type: Uint8
Describes software revision information. This is
the revision of the firmware that is currently in
use.
*Initial value depends on revision of DVC6200f.
FIRMWARE_REV_MAJOR 47.1 RO NA 0-255 *
FIRMWARE_REV_MINOR 47.2 RO NA 0-255 *
FIRMWARE_REV_BUILD 47.3 RO NA 0-255 *
IO_FIRMWARE_REV 47.4 RO NA 0-255 *
DIAG_CAL_REV 47.5 RO NA 0-255 *
FIRMWARE_REV_ALL 47.6 RO NA XX.XX.XX *
Data Type: Visible String
Describes software revision information.
The range of this parameter consists of 47.1
through 47.5 values, converted to text, and
linked together.
*Initial value depends on revision of DVC6200f
Hardware Revision
HARDWARE_REV
48 RO NA
Hardware revision
number
Factory Set
Data Type: Uint8
Describe electronic hardware revision
information.
-Continued-
