Instruction Manual
D103412X012
Detailed Setup—Transducer Block
July 2013
83
Actuator
 Actuator Manufacturer—Enter the manufacturer's identification number (ACT_MAN_ID [22]) of the actuator on
which the instrument is mounted. Select from the drop‐down list or enter the manufacturer's identification number
as defined by the Fieldbus Foundation. For Fisher, the manufacturer ID hex value is 005100.
 Actuator Model Number—Enter the type number for the actuator (ACT_MODEL_NUM [23]) on which the
instrument is mounted.
 Actuator Style—Select the Actuator Style (ACTUATOR_STYLE [42.1]), spring & diaphragm, piston double‐acting
without spring, piston single‐acting with spring, or piston double‐acting with spring.
 Actuator Serial Number—Enter the serial number (ACT_SN [24]) for the actuator on which the instrument is
mounted.
 Actuator Size—Enter the size of the actuator (ACTUATOR_SIZE [85.1]) on which the instrument is mounted.
 Actuator Fail Action—Sets actuator action to be performed upon loss of actuator air pressure (ACT_FAIL_ACTION
[21]).
 View / Edit Feedback Connection—Refer to table 4‐10 for Feedback Connection options. Choose the assembly that
matches the actuator travel range.
Note
As a general rule, do not use less than 60% of the magnet assembly travel range for full travel measurement. Performance will
decrease as the assembly is increasingly subranged.
The linear magnet assemblies have a valid travel range indicated by arrows molded into the piece. This means that the hall sensor
(on the back of the DVC6200f housing) has to remain within this range throughout the entire valve travel. See figure 2‐2. The
linear magnet assemblies are symmetrical. Either end may be up.
Table 4‐10. Feedback Connection Options
Magnet Assembly
Travel Range
mm Inch Degrees
SStem #7 4.2-7 0.17-0.28 -
SStem #19 8-19 0.32-0.75 -
SStem #25 20-25 0.76-1.00 -
SStem #38 26-38 1.01-1.50 -
SStem #50 39-50 1.51-2.00 -
SStem #100 51-100 2.01-4.00 -
SStem #210 101-210 4.01-8.25 -
SStem #1 Roller - - 60-90
RShaft Window #1 - - 60-90
RShaft Window #2 - - 60-90
RShaft End Mount - - 60-90
 Travel Sensor Motion
WARNING
If you answer YES to the prompt for permission to move the valve when setting the Travel Sensor Motion, the instrument
will move the valve through its full travel range. To avoid personal injury and property damage caused by the release of
