Lit. No. 43894, Rev. 02 65 November 1, 2016
OPERATING YOUR SNOWPLOW
6. Retighten the breather/ll plug.
7. Reconnect the snowplow battery cable to the
vehicle battery cable.
8. Turn the vehicle ignition to the "ON" or
"Accessory" position. Turn the control ON.
9. While pressing the RAISE button on the
snowplow control, note the hydraulic gauge
pressure reading as the blade is rising. (The
pressure can only be read as the blade is
rising. It may be necessary to perform this
process more than once to obtain an accurate
reading.) The recommended pressure is
350 psi.
CAUTION
Never operate the unit while adjusting the
scrape lock valve. Doing so will damage
the scrape lock valve O-rings.
5. Using a "Tee" tting, install a 500–600 psi
gauge in the lift ram base hose.
Scrape Lock
Adjustment
To Lift Ram Base
= Increase Pressure
= Decrease Pressure
