Lit. No. 43894, Rev. 02 103 November 1, 2016
FUSE REPLACEMENT
The vehicle electrical system contains several
automotive blade‑style fuses. The snowplow
park/turn and control power is covered by fuses in
the under hood snowplow wiring. The control fuse
is "hot" when the vehicle ignition switch is ON and
the electrical connections to the snowplow are
completed.
The XtremeV™ and XV2™ hydraulic unit harness
system contains four automotive blade‑style mini
fuses. The 3‑solenoid harness (to Port B on the
hydraulic unit module) and 8‑solenoid harness (to
Port C) each contain two 4‑amp mini fuses.
MAINTENANCE
The XLS™ hydraulic unit harness system contains
four automotive blade‑style mini fuses. The
2‑solenoid harness (to Port B on the hydraulic unit
module) and 6‑solenoid harness (to Port C) each
contain two 4‑amp mini fuses.
The Straight Blade and HT Series™ hydraulic
unit harness systems each contain two 4‑amp
automotive blade‑style mini fuses in the
3‑solenoid harness (to Port B on the hydraulic unit
module).
If a problem should occur and fuse replacement
is necessary, the replacement fuse must be of the
same type and amperage rating as the original.
Installing a fuse with a higher rating can damage
the system and could start a re.
