Lit. No. 43894, Rev. 02 90 November 1, 2016
HYDRAULIC SYSTEM
Fluid Level
NOTE: On XtremeV™, XV2™, and XLS™ blades,
add uid only when all rams are retracted.
NOTE: Remove ll plug slowly to relieve any
pressure in reservoir.
1. With the Minute Mount
®
2 system attached to
the vehicle, activate the control.
MAINTENANCE
CAUTION
Do not mix different kinds of hydraulic
uid. Some uids are not compatible and
may cause performance problems and
product damage.
2. For straight blades, any angle will do, but for
XtremeV, XV2, and XLS blades, move the
blade wings to the fully retracted (vee) position.
3. Activate the control FLOAT function and
manually collapse the lift ram all the way.
4. Turn the control OFF.
5. Remove the ll plug.
