Lit. No. 43894, Rev. 02 97 November 1, 2016
Air Removal – HT Series™ and Straight Blades
12. Turn the control ON and completely angle the
blade to the left and right several times. Turn
the control OFF.
13. Fill the reservoir to the top of the ll hole and
replace the ll plug.
NOTE: Loosen ll plug slowly to relieve any
pressure in the reservoir.
14. Turn the control ON and raise and lower the
snowplow several times. Activate the control
FLOAT function and manually collapse the lift
ram all the way (not required for HT Series
blades) after each lowering of the blade. Turn
the control OFF.
MAINTENANCE
15. HT Series Blades: Fill the reservoir to within
2-1/2" from the top of the ll hole and replace
the ll plug.
All other Straight Blades: Fill the reservoir to
the top of the ll hole and replace the ll plug.
WARNING
To prevent accidental movement of
the blade, always turn the control OFF
whenever the snowplow is not in use. The
power indicator light will turn OFF.
