Lit. No. 43894, Rev. 02 98 November 1, 2016
WARNING
To prevent accidental movement of
the blade, always turn the control OFF
whenever the snowplow is not in use. The
power indicator light will turn OFF.
13. Repeat Steps 11 and 12 for the passenger‑
side wing.
14. Turn the control ON and raise and lower the
snowplow several times. Activate the control
FLOAT function and manually collapse the
lift ram all the way after each lowering of the
blade. With all rams fully retracted, turn the
control OFF.
15. Fill the reservoir to the top of the ll hole and
replace the ll plug.
Air Removal – XtremeV™ and XV2™ Blades
11. Turn the control ON and completely extend
and retract the driver‑side wing several times.
With all rams fully retracted, turn the control
OFF.
12. Fill the reservoir to the top of the ll hole and
replace the ll plug.
NOTE: Loosen ll plug slowly to relieve any
pressure in the reservoir.
MAINTENANCE
