Lit. No. 43894, Rev. 02 60 November 1, 2016
Adjustment Procedure
Standard shoe kit shown. Optional shoe kits,
available for most models, have a bolt‑on shoe
holder.
ANTIWEAR SHOE ADJUSTMENT
Recommended Shoe Adjustments
For gravel surfaces: The bottom surface of the
shoe should be 1/4" to 1/2" below the cutting edge.
For hard surfaces (concrete or asphalt): The
bottom surface of the shoe should be even with
the cutting edge.
OPERATING YOUR SNOWPLOW
WARNING
Blade can drop unexpectedly. Place blade
on jack stands. Failure to do so could
result in serious personal injury.
CAUTION
Do not store unused spacers on top of the
shoe holder. This could damage the blade.
Shoe
Holder
