Manual LogoMatic G2
12
3.2 Technical data
Dimensions:
Prefabricated station without hood SM/
FM variant
Insulated SM variant
Height x Width x Depth (H x W x D in mm)
576 x 775 x 110 (depending on design)
approx. 556 x 990 x 163
Bottom connections
¾"
Heating output 10 kW (20 K)
Hot water output
35; 46 or 60 kW (in the case of domestic water heating
from 10 to 50 °C und primary nominal FL temp.), draw-o
volume 12; 17 or 22 l/min
Nominal flow line temp. (primary) 65 °C
Application limits:
Max. flow line temp. (primary) 100 °C
Permissible nominal pressure rating
(primary):
PN10
Max. dierential pressure(primary): 2.5 bar
Min. dierential pressure(primary): 0.03 bar
The factory setting of the dierential
pressure regulator:
10 kPa
Max. temp. (sanitary) 100 °C
Permissible nominal pressure rating
(sanitary):
PN10
Min. operating pressure (sanitary): 1 bar
