4.7 Mixed heating circuit (depending on variant)
Note: Function available only for LogoMatic G2 MC variants
• Mixing circuit as injection system
• MC variant with (P1) HE pump and (V4) zone valve for e.g. underfloor heating circuits
Configuration:
four-wire
control
Servomotor
24 V
FL RL
FL RL
primary
Htg.
to
RLprim
FL
prim
RL
T3
RL from
MC
Addition
MC
P1
T7
V4
FL
MC
RL
MC
