Manual LogoMatic G2
16
Unit dimensions and connections:(including example representations)
LogoMatic G2 MC-UC-SI
(shown with insulation, without front covers)
LogoMatic G2 MC-UC-DHWC-FS
(Variant with DWC)
Note: For the connections legend, see chap. 3.3
For information on installation depths with dierent equipment and product combinations, see
chapter 4.10.6.2.
(without
DWC
110mm)
MC
MC
MC
MC
UC
UC
UC
UC
