FLENDER N-BIPEX BWN - BNT Type; Figure A-3 BNT Type

Technical data
Speeds, geometry data and weights
58 Edition 09/2022 M3401-02en
A.1.3 BNT type Speeds, geometry data and weights
1/
6
1/

'
'
1'
'(

6
'$
1'
'

FigureA-3:BNT type
1 Coupling part 1/2
3/4 Coupling part 3 or 4
Size Speed
n
max
rpm
D1 D2 DA
mm
ND1
mm
ND2
mm
NL1
mm
NL2
mm
D3
mm
DE
4)
mm
S
mm
S2
TAPER-
clamp-
ing
bush
No.
Weigh
t
5)
m
kg
max
2)
mm
min.
mm
max.
1
)
mm
mm
perm
dev.
mm
24 14,500 35 10 25
2)
57 50 54 30 23 25 62 18 37 ± 1.5 1008 0.6
28 12,500 40 10 28
2)
67 58 58 35 23 28 73 20 41 ± 1.0 1108 0.8
38 10,000 48 10 28
2)
82 68 58 45 23 36 89 24 45 ± 1.5 1108 1.4
42 8,500 55 14 42
2)
97 80 86 50 26 43 105 26 48 ± 1.5 1610 2.3
48 7,500 62 14 42
2)
107 90 80 56 39 48 116 28 50 ± 2.0 1615 3.2
55 6,500 75 14 50 123 105 100 65 33 57 133 30 60 ± 2.0 2012 4.4
65 6,000 82 14 50 138 115 100 75 33 64 150 35 65 ± 2.5 2012 6.0
65 55 60 118 46 2517
3)
6.5
75 5,000 96 16 60 160 135 118 85 46 76 177 40 89.5 ± 2.5 2517 11.1
75 65 75 135 52 3020
3)
11.0
90 4,000 120 25 75 205 170 142 100 52 95 220 45 85 ± 3.0 3020 17.2
