Technical data
Cam rings
M3401-02en Edition 09/2022 63
A.5 Cam rings Cam rings
A.5.1 Use and storage of the cam rings Cam rings
Note the following concerning the use and storage of the cam rings:
• Storage possible for up to 5 years
• Protect against direct sunlight, artificial light with a high UV‐content and extreme temper-
atures
• Avoid contact with aggressive media
A.5.2 N-BIPEX cam ring (50) Cam rings
Material Hardness Comment Marking Ambient temperature
TPU 92 Shore A standard, soft red -50°C to +100°C
TPU 95 Shore A medium, shifting of the
resonant speed
green -50°C to +100°C
TPU 64 Shore D hard blue -50°C to +100°C
TableA-11: N-BIPEX cam ring
