Technical data
Shaft misalignment values during operation
M3401-02en Edition 09/2022 61
Cam rings(50) with hardness 95ShoreA
Size ∆K
1500
at n = 1,500 rpm
∆Kr
perm
1)
mm
∆Ka
perm
mm
∆S2
perm
1)
mm
19 0.15 0.27 0.29
24 0.21 0.36 0.40
28 0.23 0.45 0.47
38 0.26 0.54 0.57
42 0.31 0.63 0.68
48 0.34 0.72 0.75
55 0.36 0.81 0.86
65 0.41 0.9 0.96
75 0.47 1.08 1.14
90 0.54 1.26 1.42
TableA-7: Maximum permissible shaft misalignment values during operation for cam rings(50) with
hardness 95ShoreA
1) At a speed of 1,500rpm ΔS2
perm
corresponds to a permissible angular deviation of ΔKw
perm
=0.4°
Cam rings(50) with hardness 64ShoreA
Size ∆K
1500
at n = 1,500 rpm
∆Kr
perm
1)
mm
∆Ka
perm
mm
∆S2
perm
1)
mm
19 0.14 0.24 0.22
24 0.18 0.32 0.30
28 0.20 0.40 0.35
38 0.23 0.48 0.43
42 0.27 0.56 0.51
48 0.30 0.64 0.56
55 0.32 0.72 0.64
65 0.36 0.80 0.72
75 0.42 0.96 0.85
90 0.48 1.12 1.06
TableA-8: Maximum permissible shaft misalignment values during operation for cam rings(50) with
hardness 64ShoreA
1) At a speed of 1,500rpm ΔS2
perm
corresponds to a permissible angular deviation of ΔKw
perm
=0.3°
