18 Settings
18.1 Dialogs and menus FLUXUS F501
2020-06-30, UMFLUXUS_F501V1-3EN
122
18.1.3 Transducer distance
recommended setting: user
• user will be selected if the measuring point is always the same
• auto can be selected if the measuring point often changes
In the program branch Measuring, the recommended transducer distance will be displayed in parentheses, followed by
the entered transducer distance if the recommended and the entered transducer distance are not identical.
During the transducer positioning, in the program branch Measuring:
• only the entered transducer distance will be displayed if Transd. Distance = user is selected and the recommended
and the entered transducer distances are identical
• only the recommended transducer distance will be displayed if Transd. Distance = auto is selected
18.1.4 Error delay
The error delay is the time interval after which the entered value for the error value is transmitted to the output in case no
valid measured values are available.
• Select damping if the damping factor is to be used as the error delay. Select edit to activate the menu item Error-
val. delay in the program branch Output Options. From now on, the error delay can be entered in the program
branch Output Options.
• Press ENTER.
18.1.5 Alarm state indication
• Select on to display the alarm state during the measurement.
• Press ENTER.
18.1.6 Units of measurement
It is possible to set the units of measurement for the length, temperature, pressure, density and kinematic viscosity and
sound speed.
• Select a unit of measurement for all quantities.
• Press ENTER after each selection.
Special Funct.\...\Dialogs/Menus\Transd. Distance
Special Funct.\...\Dialogs/Menus\Error-val. delay
Special Funct.\...\Dialogs/Menus\SHOW RELAIS STAT
Transd. Distance
(50.8) 50.0 mm
