14 Data logger
14.1 Activation/Deactivation of the data logger FLUXUS F501
2020-06-30, UMFLUXUS_F501V1-3EN
94
14 Data logger
The transmitter has a data logger which stores the following data during the measurement:
• date
• time
• measuring point number
• pipe parameters
• fluid parameter
• transducer data
• sound path (reflection or diagonal arrangement)
• transducer distance
• damping factor
• storage rate
• physical quantity
• unit of measurement
• values of the totalizers
• diagnostic values
In order to store the data, the data logger has to be activated.
The available data logger can be displayed.
14.1 Activation/Deactivation of the data logger
• Select the program branch Output Options.
• Press ENTER until Store Meas.Data is displayed.
• Select yes to activate the data logger, no to deactivate it.
• Press ENTER.
14.2 Setting the storage rate
The storage rate is the frequency to transmit or store measured values. If the storage rate is not set, the storage rate previously
selected will be used.
The recommended storage rate is 4 s.
• Select a storage rate or EXTRA.
• Press ENTER.
This display will only be indicated if Store Meas.Data and/or Serial Output are activated.
• Enter the storage rate if EXTRA was selected.
• Press ENTER.
Output Options\...\Store Meas.Data
Output Options\...\Storage Rate
Output Options\...\Storage Rate\EXTRA
