9 Measurement
FLUXUS F501 9.3 Start of the measurement
79
UMFLUXUS_F501V1-3EN, 2020-06-30
9.2.5 Input of the error delay
The error delay is the time after which an error value will be sent to an output if no valid measured values are available.
This display will only be indicated if the list item edit is selected in Special Funct.\Dialogs/Menus\Error-val.
delay.
If the error delay is not entered, the damping factor will be used.
• Enter a value for the error delay.
• Press ENTER.
9.3 Start of the measurement
• Select the program branch Measuring.
• Press ENTER.
If the parameters in the program branch Parameter are
not valid or incomplete, the error message NO DATA! will
be displayed.
If the transmitter has a RS485 interface or the data logger
is activated, the measuring point number has to be entered:
Input of the measuring point number
• Enter the number of the measuring point.
• Press ENTER.
For the activation of text input, see Special Funct.\SYSTEM settings\Dialogs/Menus\Meas.Point No.:
Input of the sound path number
A value for the number of sound paths corresponding to the connected transducers and the entered parameters is recommended.
• Change the value, if necessary.
• Press ENTER.
Output Options\...\I1:Error-val. delay
Measuring
Meas.Point No.:
Sound Path
Transd. Distance
Signal test
Transd. Distance
Measurement
display
see annex A, p. 133
Measuring\Channel\Meas.Point No.:
Notice!
If the NoiseTrek parallel beam mode is enabled, it will be displayed and the measurement is immediately started.
Measuring\Channel\...\Sound Path
