4 Product description
FLUXUS F501 4.4 Keyboard
21
UMFLUXUS_F501V1-3EN, 2020-06-30
4.4 Keyboard
The keyboard has 5 keys: ENTER, BRK, C, and .
Tab. 4.2: General functions
ENTER confirmation of selection or input
BRK + C INIT: When switching on the transmitter press these 2 keys simultaneously to execute the initialization, see
section 8.8
BRK + C + ENTER
Reset: press these 3 keys simultaneously to correct a malfunction. The reset has the same effect as a restart of
the transmitter. Stored data are not affected.
BRK interruption of the measurement and selection of the main menu
Be careful not to stop a current measurement by inadvertently pressing key BRK.
Tab. 4.3: Navigation
scroll to the right or up through a scroll list
scroll to the left or down through a scroll list
Tab. 4.4: Input of numbers
move the cursor to the right
scroll through the numbers above the cursor
C move the cursor to the left
If the cursor is on the left margin:
• an already edited value will be reset to the value which was stored previously
• an unedited value will be deleted.
If the entered value is not valid, an error message will be displayed. Press ENTER and enter a correct value.
Tab. 4.5: Input of text
move the cursor to the right
scroll through the characters above the cursor
C reset all characters to the last stored entry
