8 Start-up
FLUXUS F501 8.2 Switching on
63
UMFLUXUS_F501V1-3EN, 2020-06-30
The current date is displayed.
• Press ENTER to confirm the date or to set the current date via the keys and .
• Press ENTER.
8.2 Switching on
As soon as the transmitter is connected to the power supply, the serial number of the transmitter is displayed for a short time.
It is not possible to enter any data while the serial number is displayed.
Afterwards, the main menu is displayed in the default language. The language can be changed (see section 8.5).
8.3 Program branches
The following schema shows the program branches. For a detailed overview of the menu structure see annex A.
1
SYSTEM settings contains the following menu items:
• dialogs and menus
• measurement
• outputs
• storing
• snap
• network
• serial transmission
• miscellaneous
• clock settings
• libraries
DATE
Parameter Measuring Options Special Funct.
Pipe parameters Measuring point number Physical quantity System settings
1
Fluid parameter Number of sound paths Unit of measurement Instrument information
Transducer type Transducer positioning Damping Print of measured values
Length of extension cable Measurement Output of measured value Deletion of measured values
Consistency check Program code
