7 Connection
7.1 Transducers FLUXUS F501
2020-06-30, UMFLUXUS_F501V1-3EN
50
7 Connection
7.1 Transducers
It is recommended to run the cables from the measuring point to the transmitter before connecting the transducers to
avoid load on the connectors.
Warning!
Installation, connection and start-up by unauthorized and unqualified personnel
This may result in personal or material damage or other dangerous situations.
→ Any work on the transmitter has to be carried out by authorized and qualified personnel.
Warning!
Touching live parts
Electric shock or arc faults can led to severe injuries. The measuring equipment can be damaged.
→ Prior to any work on the transmitter (e.g., installation, dismounting, connection, start-up), the transmitter has
to be disconnected from the power supply. It is not sufficient to remove the internal fuse of the instrument,
see section 7.2.
Caution!
Safety and accident prevention regulations for electrical systems and equipment
Failure to observe these regulations may lead to death or severe injury.
→ Observe the safety and accident prevention regulations for electrical systems and equipment.
Notice!
If transducers are replaced, the sensor module also has to be replaced, see section 7.1.5.
Fig. 7.1: Connection of the transducers to the transmitter
1 – transducer connection
1
