9 Measurement
FLUXUS F501 9.2 Measurement settings
73
UMFLUXUS_F501V1-3EN, 2020-06-30
9.2.3 Installation of an output
If the transmitter is equipped with outputs, they have to be
installed and activated before they can be used:
• assignment of the physical quantity (source item) to be
transmitted to the output by the source channel, and the
properties of the signal
• definition of the output behavior in case no valid measured
values are available
• activation of the installed output in the program branch
Output Options
• Select Special Funct.\SYSTEM settings\Proc. outputs.
• Press ENTER.
Selection of an output
• Select the output to be installed.
• Press ENTER.
The scroll list contains all available outputs of the transmitter:
– Current Ix (--)
– Binary Bx (--)
A tick () after a list item indicates that this output has already been installed.
• Select yes to install or reconfigure the output.
• Press ENTER.
• Select no to uninstall the output and to return to the previous menu item in order to select another output.
• Press ENTER.
Assignment of a source item
One source item has to be assigned to each selected output.
• Select the physical quantity (source item) to be transmitted to the output by the source channel.
• Press ENTER.
If a binary output is configured, only the list items Limit and Impuls will be displayed.
The source items and their scroll lists are summarized in the Tab. 9.1.
SYSTEM settings
Proc. outputs
Install Output
enable
Source item
see annex A, p. 134
Notice!
The settings will be stored at the end of the dialog. If the menu item is quit by pressing key BRK, the changes will not
be stored.
Special Funct.\SYSTEM settings\Proc. outputs
Special Funct.\SYSTEM settings\Proc. outputs\Install Output
Special Funct.\SYSTEM settings\Proc. outputs\enable I1
Special Funct.\SYSTEM settings\Proc. outputs\...\Source item
