9 Measurement
9.2 Parameter input FLUXUS H721
2022-05-15, UMFLUXUS_H721V1-5EN
108
9.2.3 Input of fluid parameters
Fluid
• Select the fluid from the scroll list.
• If the fluid is not in the scroll list, select the list item Other fluid.
• Press ENTER.
9.2.4 Definition of the HPI physical quantity
• Select one of the following HPI physical quantities:
– API gravity
– Density
– Norm. density
• Press ENTER.
• Enter the value of the HPI physical quantity (here: API gravity) at the measuring point.
• Press ENTER.
If the entered value of the HPI physical quantity at the operating point is outside the valid range, it has to be checked
whether the selected data set is adequate. The value has to be within the valid range.
.
The valid range of the selected HPI physical quantity and of the temperature, density and sound speed can be displayed.
•Select Yes to display the valid range. Select No to return to the beginning of the program branch Parameters.
• Press or to display the upper or lower limit of the valid range.
• Press ENTER.
9.2.5 Other parameters
Extension cable
In case the transducer cable is extended (e.g., between junction box and transmitter), enter the length of the extension
cable.
• Select the menu item Extension cable in the program branch Parameters.
• Enter the length of the extension cable.
• Press ENTER.
Notice!
If the HPI measuring mode has been enabled, a fluid has to be selected.
Parameters\Fluid
Parameters\Select analysis quant.
Parameters\API gravity
Parameters\Show range info
Parameters\Extension cable
