14 Outputs (TF7-*721**-******-******a-*****-**; a = U, V, D)
14.1 Configuration of a binary output FLUXUS H721
2022-05-15, UMFLUXUS_H721V1-5EN
150
Assignment of a source item
Depending on the selected source item, status or event values can be output.
• Select the source item.
• Press ENTER.
14.1.1 Definition of the switching function for the status/event value
• Select the switching function for the output of the status/event value.
• Press ENTER.
If no measurement is carried out, all binary outputs are open (de-energized), independent of the set switching condition.
Terminal assignment
The terminals for the connection of the output are displayed.
By pressing or further information is displayed.
• Press ENTER.
Output function test
The function of the output can now be tested.
• Connect a multimeter to the output.
•Select Yes to test the output. Select No to display the next menu item.
• Press ENTER.
Options\Channel A\Outputs\...\Source item
Tab. 14.1: Output of status values or event values
source item status value event value
physical quantities Flow quantities x
Fluid properties x
Miscellaneous
(Custom. Input 1...4)
x
Sound speed x
Totalizers x
events Event trigger x
Tab. 14.2: Selection of the switching condition
property switching function description
Status OK
(status value)
NC • valid measured value: binary output is closed
• invalid measured value: binary output is open
NO • valid measured value: binary output is open
• invalid measured value: binary output is closed
Idle state
(event value)
NO • event occurs: binary output is closed
• event has not occurred yet: binary output is open
NC • event occurs: binary output is open
• event has not occurred yet: binary output is closed
Options\Channel A\Outputs\...\Output info
Options\Channel A\Outputs\...\B1 Test signal
