15 Outputs (TF7-*72***-******-******a-*****-**; a = M, P, Q)
15.1 Configuration of a digital output as binary output FLUXUS H721
2022-05-15, UMFLUXUS_H721V1-5EN
156
Output function test
The function of the output can now be tested.
• Connect a multimeter to the output.
•Select Yes to test the output. Select No to display the next menu item.
• Press ENTER.
• Select a list item as test value.
• Press ENTER.
•Select Repeat to repeat the test or Finish to display the next menu item.
• Press ENTER.
•Select Yes to test the status of the output signal. Select No to display the next menu item.
• Press ENTER.
• Select a list item as test value.
• Press ENTER.
Options\Channel A\Outputs\...\B1 Test signal
Options\Channel A\Outputs\...\B1 Enter test value
Tab. 15.4: Output function test – signal
list item description
NC • binary output is energized
• measured value has to be low ohmic
NO • binary output is de-energized
• measured value has to be high ohmic
Options\Channel A\Outputs\...\B1 Test mea. range
Options\Channel A\Outputs\...\B1 Enter test value
