16 Inputs
16.1 Configuration of an input FLUXUS H721
2022-05-15, UMFLUXUS_H721V1-5EN
164
16.1.4 Binary inputs
The transmitter can be equipped with max. 4 binary inputs. Via the binary inputs, it is possible to remotely trigger some
functions of the transmitter.
Inversion of the input
•Select Yes if a function is to be triggered when no voltage is existing (negated logic).
•Select No if a function is to be triggered when voltage is existing.
16.1.5 Terminal assignment
The terminals for the connection of the input are displayed.
By pressing or further information is displayed.
• Press ENTER.
16.1.6 Function test of the input
The function of the installed input can now be tested.
Analog input
• Connect the signal source to the input.
•Select Yes to test the input signal. Select No to display the next menu item.
• Press ENTER.
• If the transmitter displays a value (here: Current), the input functions correctly.
• Press ENTER.
•Select Repeat to repeat the test or Finish to display the next menu item.
• Press ENTER.
•Select Yes to test the assignment of the measured value to the input signal. Select No to display the next menu item.
• Press ENTER.
• If the transmitter displays a value (here: Temperature), the input functions correctly.
• Press ENTER.
•Select Repeat to repeat the test or Finish to display the next menu item.
• Press ENTER.
Special functions\Inputs\Binary Bx\Negate input
Special functions\Inputs\...\Input info
Special functions\Inputs\...\I1 Test signal
Special functions\Inputs\...\I1 Test signal\Current
Special functions\Inputs\...\I1 Test mea. range
Special functions\Inputs\...\I1 Test mea. range\Temperature
