5.4.4.3 Frequency Mode
In Frequency mode, the meter measures and displays the frequency. Frequency mode is
available when measuring AC current or voltage.
Important note: Do not switch to the Frequency mode until the meter is setup and
actively measuring the voltage or current signal.
Press and hold the MODE button to select and enable Frequency mode.
5.4.4.4 MIN/MAX Mode
In MIN/MAX mode, the meter captures and displays the Minimum and Maximum
readings and updates only when a higher/lower value is registered.
1. Press and hold the MIN/MAX button to access the MIN/MAX mode.
2. The down arrow will appear and the reading displayed next to it will
represent the lowest reading encountered since the MIN/MAX button was first
pressed.
3. The up arrow will also appear and the reading displayed next to it will
represent the highest reading encountered since the MIN/MAX button was first
pressed.
4. The meter will continue to display the real time measurement value in the
normal display area.
5. Press and hold the MIN/MAX button for 2 seconds to exit the MIN/MAX mode.
The meter will return to normal operation and the MIN/MAX memories will be
reset.
5.4.4.5 VFD Mode (low pass filter)
The VFD mode eliminates high frequency noise in AC voltage measurements by means of
a low-pass filter. The VFD mode is designed for such applications as variable frequency
drives (VFD) and inverters. Press the VFD button to activate or deactivate the VFD mode.
The VFD display icon is displayed when the mode is active.
