FLIR CM174 USER MANUAL Document Identifier: CM174-en-US_AC
27
Cross hairs
1. Press and hold the IGM button to access the Programming menu.
2. Scroll to the Cross hairs icon using the arrow buttons.
3. Use the OK button to toggle the Cross hairs ON and OFF.
4. When done, use the arrow buttons to continuing scrolling the Programming
menu or use the Return button to exit the programming menu.
Diode mode
1. Press and hold the IGM button to access the Programming menu.
2. Scroll to the Diode symbol using the arrow buttons.
3. Use the OK button to toggle CLASSIC and SMART modes.
4. When done, use the arrow buttons to continuing scrolling the Programming
menu or use the Return button to exit the programming menu.
Auto Power OFF mode
1. Press and hold the IGM button to access the Programming menu.
2. Scroll to the APO icon using the arrow buttons
3. Use the OK button to open the APO screen.
4. Use the arrow buttons to step through the presets (OFF, 1, 2, 5, 10 minutes).
5. Press the OK button to select a highlighted preset (the circle will switch to the
color blue).
6. Press the Return button to return to the programming menu.
7. ? Help screen
8. Press and hold the IGM button to access the Programming menu.
9. Scroll to the Help (?) icon using the arrow buttons.
10. Press the OK button to view contact and other information.
11. Use the Return button to return to the Programming menu.
Information screen
1. Press and hold the IGM button to access the Programming menu.
2. Scroll to the information icon using the arrow buttons.
3. Press the OK button.
4. View the firmware version and the last calibration date.
5. Use the Return button to return to the Programming menu.
